Stepper Motor Drive and Controller Forward Control Drive Integration

Description:

[Controller and ]: Integrated stepper motor controller and . This is a dedicated control module for single axis stepper, enabling multiple scenarios and applications.

[Forward and]: 30V universal, 4A, TTL serial communication, delay, speed, angle, distance can be adjusted.

[Multiple working modes]: the module has a variety of built in fixed operating modes, so users can quickly select the appropriate motion trajectory. Save and set distance / speed/delay / number of loops. It can be run independently as a module or used in conjunction with other systems.

[ Display]: Stepper Motor Drive and Controller has a display for easy browsing of various parameters and high precision control.

[Wide Application]: Stepper Motor Controller can be used in general industrial control situations.

Specification:

Motor : common cathode

Instruction features: streamlined optimization of many commonly used instructions

Speed Up and deceleration control: Yes

input connection protection: yes

Communication control: TTL serial port

Main functions of the system: automatic, manual, settings, Serial Port Control

number of cycle Operations: 1-9999 Times

Forward rotation delay Time: 0.0-999.9 seconds

delay Time: 0.0-999.9 Seconds

сегмент selection Range: 1-128 segments

product usage environment: - C-60°C (no condensation)

size chart:

7.9cmx4.3cmx4.1cm/3.11inchx1.69inchx1.61inch

Package Includes:

1 Stepper Motor Drive and Controller
